Flexibility Expandable Durable Nylon 66 Cable Sleeve for automotive industry
Product Introduction
Nylon expandable sleeving is flame-retardant and halogen-free. It offers durable abrasion resistance in a wide range of industrial
applications. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky
or large connectors.Totally expanded the sleeving can reach at least one point five times than the initial dimension.
Datasheet
| Nominal size(W) | Part No. | Expanded range | Packing(L) | ||
| Inch | mm | Min.(I) | Max.(O) | Standrd spool | |
| 1/8" | 3.0 | BS-PA003 | 1.0 | 6.0 | 1000m/roll |
| 1/4" | 6.0 | BS-PA006 | 3.0 | 9.0 | 500m/roll |
| 5/16" | 8.0 | BS-PA008 | 5.0 | 16.0 | 300m/roll |
| 3/8" | 10.0 | BS-PA010 | 7.0 | 19.0 | 300m/roll |
| 1/2" | 12.0 | BS-PA012 | 8.0 | 24.0 | 300m/roll |
| 5/8" | 16.0 | BS-PA016 | 10.0 | 27.0 | 300m/roll |
| 3/4" | 20.0 | BS-PA019 | 14.0 | 30.0 | 300m/roll |
| 1" | 25.0 | BS-PA025 | 18.0 | 35.0 | 200m/roll |
| 1-1/4" | 30.0 | BS-PA032 | 20.0 | 50.0 | 200m/roll |
| 1-1/2" | 40.0 | BS-PA038 | 30.0 | 60.0 | 100m/roll |
| 1-3/4" | 45.0 | BS-PA045 | 35.0 | 75.0 | 100m/roll |
| 2" | 50.0 | BS-PA050 | 40.0 | 80.0 | 100m/roll |
| 2-1/2" | 64.0 | BS-PA064 | 45.0 | 105.0 | 100m/roll |
| 3" | 76.0 | BS-PA076 | 64.0 | 120.0 | 100m/roll |
Application
It's used to cover cables, wire harnesses, tubes, industrial hoses,where is required an additional protection. Most commonly used
to protect wire harness, cable assemblies, air conditioned pipes, fluid pipes in automotive, aerospace and military applications.
