5052/5056/5083 Different Size Aluminum Alloy Tube Aluminum Round Tube
5052 aluminum alloy is a kind of Al Mg alloy, which is widely used, especially in the construction industry. It is the most promising alloy. It has good corrosion resistance, weldability, cold workability and medium strength. The main alloy element of 5052 aluminum alloy is magnesium, which has good forming and processing performance, corrosion resistance, weldability and medium strength. It is used to manufacture aircraft oil tank, oil pipe, as well as sheet metal parts of traffic vehicles and ships, instruments, street lamp bracket and rivets, hardware products, electric appliance outer shell, etc.

5052 aluminum alloy is the most widely used antirust aluminum, which has high strength, especially fatigue strength: high plasticity and corrosion resistance, can not be strengthened by heat treatment, good plasticity in semi cold work hardening, low plasticity in cold work hardening, good corrosion resistance, good weldability, poor machinability and polishing. It is mainly used for low load parts that require high plasticity and good weldability and work in liquid or gas medium, such as oil tank, gasoline or lubricating oil conduit, various liquid containers and other small load parts made by deep drawing: wire rod is used for rivets.

Chemical Composition
Mechanical Property
Tensile strength σ B (MPA) 173-244
Conditional yield strength σ 0.2 (MPA) ≥ 70
Density 2.68g/cm3
Note: longitudinal mechanical properties of pipe at room temperature

Aluminum is highly reductive at high temperatures and can be used to smelt high melting point metals. (This method of smelting metal is called "aluminum heat method") Aluminum is malleable and can be made into aluminum foil for packaging. The corrosion resistance of aluminum (especially oxidation, because its oxide alumina increases the corrosion resistance and heat resistance of aluminum), the appearance quality is good, and the price is moderate. It is the material of choice for computer casings. The use of a substance depends to a large extent on the nature of the substance. Because aluminum has many excellent properties, aluminum has an extremely wide range of uses.

Aluminum tube: (diameter φ2 - φ460, wall thickness 0.3-40mm)
Pure aluminum tube, alloy aluminum tube, seamless aluminum tube (extrusion, drawing), large diameter aluminum tube, thick wall aluminum tube, alumina tube, aluminum flat tube, aluminum square tube, elliptical tube, coil, fine pull Pull out the aluminum tube.
Technical Parameter

5052 aluminum alloy is a kind of Al Mg alloy, which is widely used, especially in the construction industry. It is the most promising alloy. It has good corrosion resistance, weldability, cold workability and medium strength. The main alloy element of 5052 aluminum alloy is magnesium, which has good forming and processing performance, corrosion resistance, weldability and medium strength. It is used to manufacture aircraft oil tank, oil pipe, as well as sheet metal parts of traffic vehicles and ships, instruments, street lamp bracket and rivets, hardware products, electric appliance outer shell, etc.

5052 aluminum alloy is the most widely used antirust aluminum, which has high strength, especially fatigue strength: high plasticity and corrosion resistance, can not be strengthened by heat treatment, good plasticity in semi cold work hardening, low plasticity in cold work hardening, good corrosion resistance, good weldability, poor machinability and polishing. It is mainly used for low load parts that require high plasticity and good weldability and work in liquid or gas medium, such as oil tank, gasoline or lubricating oil conduit, various liquid containers and other small load parts made by deep drawing: wire rod is used for rivets.

Chemical Composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Single | Other |
5052 | ≤0.25 | ≤0.4 | ≤0.10 | ≤0.10 | 2.2-2.8 | 0.15-0.30 | ≤0.10 | ≤0.05 | ≤0.15 |
Mechanical Property
Tensile strength σ B (MPA) 173-244
Conditional yield strength σ 0.2 (MPA) ≥ 70
Density 2.68g/cm3
Note: longitudinal mechanical properties of pipe at room temperature

Aluminum is highly reductive at high temperatures and can be used to smelt high melting point metals. (This method of smelting metal is called "aluminum heat method") Aluminum is malleable and can be made into aluminum foil for packaging. The corrosion resistance of aluminum (especially oxidation, because its oxide alumina increases the corrosion resistance and heat resistance of aluminum), the appearance quality is good, and the price is moderate. It is the material of choice for computer casings. The use of a substance depends to a large extent on the nature of the substance. Because aluminum has many excellent properties, aluminum has an extremely wide range of uses.

Aluminum tube: (diameter φ2 - φ460, wall thickness 0.3-40mm)
Pure aluminum tube, alloy aluminum tube, seamless aluminum tube (extrusion, drawing), large diameter aluminum tube, thick wall aluminum tube, alumina tube, aluminum flat tube, aluminum square tube, elliptical tube, coil, fine pull Pull out the aluminum tube.
Technical Parameter
Alloy Type | Tensile Strength (250ºC/MPa) | 0.2% Yield Strength (MPa) | Hardness (HB) | Elongation rate (%) |
5052-H112 | 175 | 195 | 60 | 12 |
5083-H112 | 180 | 211 | 65 | 14 |
6061-T651 | 290 | 240 | 95 | 12 |
6082-T651 | 315 | 280 | 94 | 12 |
7050-T651 | 510 | 455 | 135 | 10 |
7075-T651 | 572 | 503 | 150 | 11 |
2024-T351 | 470 | 325 | 120 | 20 |
